Lower carbon, versatile performance

Guardian NEXA 6 lower carbon glass has an embodied carbon value of 6.38 kg CO2e/m2 for a 4 mm glass thickness. This represents a reduction of more than 40%* when compared to the average EU float glass dataset, and more than 30% when compared to standard 4mm Guardian ExtraClear^™ float glass. Guardian NEXA 6 can be laminated and/or used as a base glass for all Guardian Glass range of products – such as the Guardian SunGuard™, Guardian Bird1st^™ Lami or Guardian ClimaGuard™ – to add features such as energy efficiency, bird deterrence, or sound reduction when laminated.

*When comparing A1-A3 GWP (Global Warming Potential) value of Nexa6 vs Sphera Database 2022 Dataset for EU-28 Float flat glass (valid as of December 2024), reduction calculated is -41.5%. A1-A3 embodied carbon value derived from the LCAs and pending verification for conformance to ISO 14040/44, EN 15804, and the Product Category Rules (PCR) through a program operator and independent reviewer.

Product information

Substrates

Guardian NEXA 6 3-8 mm

Applications

Partitions
Storefronts
Windows
Skylights
Facades
Roof window
Curtain walls
Doors

Manufacturing Options

Heat Strengthened
Heat Soaked
Annealed
Bent
Laminated

Recommended Coating Positions

Not applicable

Maximum Size

<3210x9000mm

Edge Deletion

Glass Type

Float glass

Glass Functions

Aesthetics

Fabrication Options

Can be Laminated
Can be in an Insulating Glass Unit

Appearance

Neutral

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Monolithic

Monolithic

GLASS: Guardian Float Glass Nexa™ 6 (CE) Glass, 4mm

Calculated Values are in accordance with EN 410:2011 / EN 673:2011

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

91 %

Reflectance outside (ρv)

8 %

Reflectance inside (ρv)

8 %

General Color Rendering Index (CRI)

Ultraviolet

Transmittance UV (τuv)

74 %

Solar Energy

Solar transmittance (τe)

87 %

Reflectance outside (ρe)

8 %

Reflectance inside (ρe)

8 %

Solar absorptance (αe)

6 %

Solar Factor (g)

88 %

Shading Coefficient (sc)

1.01

Thermal properties

U-Value (Ug)

5.8 W/m²·K

Embodied Co<sub>2</sub>

[eq. kg/m²] A1-A3

6.16

Performance Calculations
