Elevate window performance without the pain of adding panes

Guardian ClimaGuard IS 20 interior surface coating can help dial up thermal insulation and solar control. IS 20 can help lower U-value when applied to the fourth surface of a double-pane insulated glass unit in combination with other ClimaGuard low-E coatings. To further amplify performance, apply ClimaGuard IS 20 to the sixth surface of a triple-glazed unit.

Product information

Substrates

Clear Float 2.3 mm (3/32") - 5 mm (13/64")

Applications

Windows
Skylights
Facades
Curtain walls
Doors

Manufacturing Options

Tempered
Laminated

Recommended Coating Positions

Surface 6 (triple IGU)

Maximum Size

<60"x96" (1524x2438mm)

Edge Deletion

Glass Type

Low E

Glass Functions

Thermal insulation

Fabrication Options

Can be used Monolithic
Can be in an Insulating Glass Unit

Appearance

Clear

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option

Substrate

There is only one substrate available for this product

View

Left sky conditions

Right sky conditions

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Launch Glass Visualizer

Calculate Performance Values & Generate BIM Files

Generate product performance data for custom glass make-ups and create detailed BIM object files for your project

Calculate

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Double Glazed
Monolithic
Triple Glazed

Double Glazed

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm)

GAP: 10% Air, 90% Argon 12.7mm

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm) (4-ClimaGuard® IS-20 (North America))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

80 %

Reflectance outside (ρv)

16 %

Reflectance inside (ρv)

16 %

General Color Rendering Index (CRI)

98.4

Ultraviolet

Transmittance UV (τuv)

57 %

Solar Energy

Solar transmittance (τe)

67 %

Reflectance outside (ρe)

15 %

Reflectance inside (ρe)

15 %

Solar absorptance (αe)

17 %

Solar Heat Gain Coefficient (SHGC)

0.73

Shading Coefficient (sc)

0.84

Thermal properties

Winter night U-Value

0.348 Btu/hr·ft²·F

Summer day U-value

0.337 Btu/hr·ft²·F

Light to Solar Gain

Light to Solar Gain (LSG)

1.10

Embodied Co2

[eq. kg/m²] A1-A3

19.72

Monolithic

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm) (2-ClimaGuard® IS-20 (North America))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

88 %

Reflectance outside (ρv)

9 %

Reflectance inside (ρv)

9 %

General Color Rendering Index (CRI)

99.2

Ultraviolet

Transmittance UV (τuv)

70 %

Solar Energy

Solar transmittance (τe)

77 %

Reflectance outside (ρe)

10 %

Reflectance inside (ρe)

10 %

Solar absorptance (αe)

13 %

Solar Heat Gain Coefficient (SHGC)

0.79

Shading Coefficient (sc)

0.92

Thermal properties

Winter night U-Value

0.675 Btu/hr·ft²·F

Summer day U-value

0.528 Btu/hr·ft²·F

Light to Solar Gain

Light to Solar Gain (LSG)

1.10

Embodied Co2

[eq. kg/m²] A1-A3

11.52

Triple Glazed

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm)

GAP: 10% Air, 90% Argon 12.7mm

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm)

GAP: 10% Air, 90% Argon 12.7mm

GLASS: Guardian Clear Glass (North America) Glass, 1/8" (3mm) (6-ClimaGuard® IS-20 (North America))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

73 %

Reflectance outside (ρv)

22 %

Reflectance inside (ρv)

21 %

General Color Rendering Index (CRI)

97.6

Ultraviolet

Transmittance UV (τuv)

48 %

Solar Energy

Solar transmittance (τe)

59 %

Reflectance outside (ρe)

20 %

Reflectance inside (ρe)

18 %

Solar absorptance (αe)

22 %

Solar Heat Gain Coefficient (SHGC)

0.67

Shading Coefficient (sc)

0.77

Thermal properties

Winter night U-Value

0.237 Btu/hr·ft²·F

Summer day U-value

0.250 Btu/hr·ft²·F

Light to Solar Gain

Light to Solar Gain (LSG)

1.09

Embodied Co2

[eq. kg/m²] A1-A3

27.93
