SunGuard® High Performance

HP Royal Blue 40

HP Royal Blue 40
 Download Brochure Calculate Performance Generate BIM Files Generate specification Find a Supplier
Hide the product comparison tool ( Products)
Show the product comparison tool ( Products)
Compare Product
Placeholder
Download Brochure Generate BIM Files Generate specification Find a Supplier

Add more products here

Give your project the royal treatment

SunGuard® HP Royal Blue 40 lets architects and specifiers create buildings with excellent solar control that delivers dramatic energy savings to meet or exceed local and regional building energy codes. It also offers excellent reflectivity and a regal blue appearance, along with optical clarity, uniformity and excellent selectivity. Usher in low-E performance without the cost of blue glass. SunGuard HP Royal Blue 40 is also durable enough to be tempered, heat-strengthened, curved, laminated or screen-printed. Architects have trusted it in projects across the globe.

HP Royal Blue 40
All Rights reserved

Product information

Substrates
  • Clear 3-12 mm
Applications
  • Windows
  • Facades
  • Roof window
  • Curtain walls
  • Doors
Manufacturing Options
  • Heat Strengthened
  • Heat Soaked
  • Annealed
  • Tempered
Recommended Coating Positions
  • Surface 2 (double IGU)
Maximum Size
  • <3210x6000mm
Edge Deletion
  • No
Glass Type
  • Single Silver Coated Glass
Glass Functions
  • Solar control
  • Thermal insulation
Fabrication Options
  • Must be used in an Insulating Glass Unit
Appearance
  • Blue

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option
There is only one substrate available for this product

View

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

Original Image
Modified Image

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Launch Glass Visualizer
Calculate Performance Values & Generate BIM Files
Generate product performance data for custom glass make-ups and create detailed BIM object files for your project
Calculate
Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

  • Default Performance Data
  • Performance Calculations

  • Double Glazed

  • Triple Glazed

Double Glazed

pim/components/structure/pim-double

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm (2-SunGuard® HP Royal Blue 40 (Middle East & Africa))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm

Calculated Values are in accordance with NFRC2010

Performance Values

Visible Light
Transmittance (τv)
38 %
Reflectance outside (ρv)
25 %
Reflectance inside (ρv)
23 %
General Color Rendering Index (CRI)
94.4
Ultraviolet
Transmittance UV (τuv)
16 %
Solar Energy
Solar transmittance (τe)
23 %
Reflectance outside (ρe)
29 %
Reflectance inside (ρe)
35 %
Solar absorptance (αe)
49 %
Solar Heat Gain Coefficient (SHGC)
0.29
Shading Coefficient (sc)
0.33
Thermal properties
Winter night U-Value
1.744 W/m²·K
Summer day U-value
1.722 W/m²·K
Light to Solar Gain
Light to Solar Gain (LSG)
1.33
Embodied Co<sub>2</sub>
[eq. kg/m²] A1-A3
39.35

Triple Glazed

pim/components/structure/pim-triple

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm (2-SunGuard® HP Royal Blue 40 (Middle East & Africa))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 4mm

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (Middle East & Africa) Glass, 6mm

Calculated Values are in accordance with NFRC2010

Performance Values

Visible Light
Transmittance (τv)
35 %
Reflectance outside (ρv)
26 %
Reflectance inside (ρv)
27 %
General Color Rendering Index (CRI)
93.7
Ultraviolet
Transmittance UV (τuv)
14 %
Solar Energy
Solar transmittance (τe)
20 %
Reflectance outside (ρe)
29 %
Reflectance inside (ρe)
32 %
Solar absorptance (αe)
51 %
Solar Heat Gain Coefficient (SHGC)
0.26
Shading Coefficient (sc)
0.30
Thermal properties
Winter night U-Value
1.295 W/m²·K
Summer day U-value
1.355 W/m²·K
Light to Solar Gain
Light to Solar Gain (LSG)
1.34
Embodied Co<sub>2</sub>
[eq. kg/m²] A1-A3
51.13
