A Low-E Glass with High Transparency and Thermal Insulation

SunGuard® High Performance Neutral 55 is a low-emissive glass that offers high transparency with thermal insulation to suit challenging projects. With visible light transmission of 53%, this glass can help meet the demand for greater use of natural light in current architecture. SunGuard® High Performance Neutral 55 combines transparency, low reflection, and solar heat gain in one product. It also has a neutral appearance that help enhance the aesthetics of many buildings.

SunGuard® High Performance Neutral 55 can be used in various applications, such as facades, roofs, skylights, windows, and spandrels. It is especially recommended for laminated applications, where it can provide additional benefits of safety, security, and acoustic performance. SunGuard® High Performance Neutral 55 requires edge deletion and must be laminated or used in insulated glass units (IGU), and it can be tempered in both compositions.

If you are looking for a high-performance glass that offers great transparency and solar control, SunGuard® High Performance Neutral 55 is a good choice for your project.

Product information

Substrates

Clear 4-12 mm

Applications

Windows
Skylights
Facades
Spandrel
Roof window

Manufacturing Options

Edge deletion
Laminated
Tempered

Recommended Coating Positions

Maximum Size

<2600x3600mm

Edge Deletion

Glass Type

Low E

Glass Functions

Solar control

Fabrication Options

Can be Laminated
Can be in an Insulating Glass Unit

Appearance

Neutral

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option

Substrate

There is only one substrate available for this product

View

Left sky conditions

Right sky conditions

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Launch Glass Visualizer

Calculate Performance Values & Generate BIM Files

Generate product performance data for custom glass make-ups and create detailed BIM object files for your project

Calculate

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Monolithic Laminate
Double Glazed

Monolithic Laminate

pim/components/structure/pim-mono-laminate

GLASS: Guardian Clear Glass (South America) Glass, 5/32" (4mm) (2-SunGuard® HP Neutral 55 (South America))

INTERLAYER: 0.015" (0.38mm) Clear PVB, 0.381mm

GLASS: Guardian Clear Glass (South America) Glass, 5/32" (4mm)

Calculated Values are in accordance with EN 410:2011 / EN 673:2011

Performance Values

Visible Light

Transmittance (τv)

54 %

Reflectance outside (ρv)

22 %

Reflectance inside (ρv)

17 %

General Color Rendering Index (CRI)

Ultraviolet

Transmittance UV (τuv)

0 %

Solar Energy

Solar transmittance (τe)

36 %

Reflectance outside (ρe)

32 %

Reflectance inside (ρe)

26 %

Solar absorptance (αe)

33 %

Solar Factor (g)

44 %

Shading Coefficient (sc)

0.50

Thermal properties

U-Value (Ug)

5.6 W/m²·K

Double Glazed

GLASS: Guardian Clear Glass (South America) Glass, 5/32" (4mm) (2-SunGuard® HP Neutral 55 (South America))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (South America) Glass, 5/32" (4mm)

Calculated Values are in accordance with EN 410:2011 / EN 673:2011

Performance Values

Visible Light

Transmittance (τv)

54.6 %

Reflectance outside (ρv)

25.1 %

Reflectance inside (ρv)

15.8 %

General Color Rendering Index (CRI)

97.3

Ultraviolet

Transmittance UV (τuv)

32.1 %

Solar Energy

Solar transmittance (τe)

38.1 %

Reflectance outside (ρe)

31.7 %

Reflectance inside (ρe)

29.0 %

Solar absorptance (αe)

30.2 %

Solar Factor (g)

41.5 %

Shading Coefficient (sc)

0.48

Secondary Heat Transfer (qi)

3.4

Thermal properties

U-Value (Ug)

1.7 W/m²·K
